G104SN02 V2,TFT Displays,LCD parts, LCD for industrial, LCD Modules, STN, TFT, Color STN, EL display, Display>

G104SN02 V2
Size:  10.4
MFG:  AUO
Resolution:  800 x 600
Backlight:  WLED
Brightness:  400
Interface:  LVDS
Overall Size(mm):  243.0 x 184.0 x 10.6
A.A(mm):  211.2 x 158.4
Operation Temp:  -30℃~85℃
PDF:   G104SN02-V2.pdf
Features:  Anti-glare, wide view angle

Select	Size	Part NO.	MFG	Resolution	Backlight	Brightness	Interface	Overall Size(mm)	A.A(mm)	Operation Temp
	10.4	G104VN01 V0	AUO	640 x 480	CCFL	450	TTL	243.0 x 176.6 x 11.5	211.2 x 158.4	-30℃~80℃
	10.4	G104VN01 V1	AUO	640 x 480	CCFL	450	LVDS	243.0 x 176.6 x 8.0	211.2 x 158.4	-30℃~85℃
	10.4	A104SN03 V1	AUO	800 x 600	WLED	300	RGB	228.4 x 175.4 x 6.2	211.2 x 158.4	-10℃~60℃
	10.4	G104SN02 V0	AUO	800 x 600	CCFL	400	LVDS	243.0 x 184.0 x 10.6	211.2 x 158.4	0℃~50℃
	10.4	G104SN02 V1	AUO	800 x 600	CCFL	400	LVDS	243.0 x 184.0 x 10.6	211.2 x 158.4	-30℃~85℃
	10.4	G104SN03 V0	AUO	800 x 600	CCFL	230	LVDS	236.0 x 174.3 x 5.6	211.2 x 158.4	0℃~50℃
	10.4	G104SN03 V1	AUO	800 x 600	CCFL	230	LVDS	236.0 x 174.3 x 5.6	211.2 x 158.4	0℃~50℃
	10.4	G104SN03 V5	AUO	800 x 600	WLED	230	LVDS	236.0 x 176.9 x 5.7	211.2 x 158.4	-20℃~70℃
	10.4	G104SN05 V0	AUO	800 x 600	CCFL	1500	LVDS	243.0 x 184.0 x 27.2	211.2 x 158.4	0℃~50℃
	10.4	G104XVN01.0	AUO	1024 x 768	WLED	400				-30℃~80℃

Select	Size	Part NO.	MFG	Resolution	Backlight	Brightness	Interface	Overall Size(mm)	A.A(mm)	Operation Temp
	10.4	LTA104D182F	Thoshiba	800 x 600	CCFL	400	LVDS	242.0 x 178.4 x 13.2	211.2 x 158.4	-20℃~70℃
	10.4	A104SN03 V1	AUO	800 x 600	WLED	300	RGB	228.4 x 175.4 x 6.2	211.2 x 158.4	-10℃~60℃
	10.4	G104SN02 V0	AUO	800 x 600	CCFL	400	LVDS	243.0 x 184.0 x 10.6	211.2 x 158.4	0℃~50℃
	10.4	G104SN02 V1	AUO	800 x 600	CCFL	400	LVDS	243.0 x 184.0 x 10.6	211.2 x 158.4	-30℃~85℃
	10.4	G104SN03 V0	AUO	800 x 600	CCFL	230	LVDS	236.0 x 174.3 x 5.6	211.2 x 158.4	0℃~50℃
	10.4	G104SN03 V1	AUO	800 x 600	CCFL	230	LVDS	236.0 x 174.3 x 5.6	211.2 x 158.4	0℃~50℃
	10.4	G104SN03 V5	AUO	800 x 600	WLED	230	LVDS	236.0 x 176.9 x 5.7	211.2 x 158.4	-20℃~70℃
	10.4	G104SN05 V0	AUO	800 x 600	CCFL	1500	LVDS	243.0 x 184.0 x 27.2	211.2 x 158.4	0℃~50℃
	10.4	NL8060BC26-17	NEC	800 x 600	CCFL	250	RGB	243.0 x 185.1 x 11.5	211.2 x 158.4	0℃~50℃
	10.4	AA104SG01	MIT	800 x 600	CCFL	400	LVDS	243.0 x 181.6 x 12.2	211.2 x 158.4	-20℃~70℃
	10.4	AA104SG04	MIT	800 x 600	CCFL	400	LVDS	243.0 x 181.6 x 12.2	211.2 x 158.4	-20℃~70℃
	10.4	LQ104S1DG21	SHARP	800 x 600	CCFL	350	RGB	246.5 x 179.4 x 15.5	211.2 x 158.4	-10℃~65℃
	10.4	LQ104S1DG31	SHARP	800 x 600	CCFL	350	RGB	243.0 x 183.8 x 11.5	211.2 x 158.4	-30℃~80℃
	10.4	LQ104S1LG61	SHARP	800 x 600	CCFL	420	LVDS	246.5 x 179.4 x 13.7	211.2 x 158.4	-30℃~80℃
	10.4	TS104SAALC01	TIANMA	800 x 600	CCFL	230	LVDS	236.0 x 176.9 x 5.6	211.2 x 158.4	-20℃~70℃
	10.4	TM104SDH01	TIANMA	800 x 600	WLED	400	LVDS	236.0 x 176.9 x 5.6	211.2 x 158.4	-30℃~80℃
	10.4	LSA40AT9001 V2	Innolux	800 x 600	WLED	250	RGB	228.4 x 175.4 x 5.9	211.2 x 158.4	-30℃~85℃
	10.4	G104S1-L01	Innolux	800 x 600	WLED	400	LVDS	243.0 x 184.0 x 6.7	211.2 x 158.4	-30℃~70℃
	10.4	G104AGE-L02	Innolux	800 x 600	WLED	400	LVDS	243.0 x 184.0 x 8.0	211.2 x 158.4	-30℃~85℃
	10.4	G104AGE-L02	Innolux	800 x 600	WLED	400	LVDS	243.0 x 184.0 x 8.0	211.2 x 158.4	-30℃~85℃
	10.4	BA104S01-100	BOE	800 x 600	WLED	400	LVDS	236.0 x 176.9 x 5.6	211.2 x 158.4	-20℃~70℃
	10.4	ML1041	MILLO	800 x 600	265.5 x 207.3 x 45.6	213.0 x 160.0	VGA	Optional
